DNC-2065
Underwater Power Bulkhead Connector M16 for RED DSMC2 IO module
* This underwater bulkhead connector designed to feed RED DSMC2 I/O Salty Surf housing from the surface.
* The bulkhead connector DNC-2065 comes with Dive And See pin-out style from one end (outside the housing), and 6 pin Lemo connector on the inside.
* Protective cap is include
* Material: Marine Aluminum with Hard Anodizing coating
* Contacts of the bulkhead connector, made from Gold plated brass
* Compatible with external Power cable DNC-1106.
Brief Description
We have developed a Power bulkhead connector to feed RED camera, when using RED DSMC2 IO module from the surface, using external batteries.
High capacity V-Mount battery produced an extensive amount of run time for the camera, such a ROLUX RL-95S.
Connector DNC-2065 fits the port of the underwater housings, such Salty Surf housing, Aquatica, Aquatech, Nauticam.
Thread of the connector M16x1, the length of the thread is 12.7mm (0.5 inches).
If you need for Nauticam M16x1 housings specify "short thread" 6mm (0.25 inches).
Water Block
Underwater Bulkhead connector comes with the built-in water block.
Water block keep the vacuum inside of the housing when using the AirLock Vacuum System.
Also protect the housing against penetration of the water, if something happening with external cable or connection between external Power cable and bulkhead connector.
Options
Custom length available.
Compatibility
Bulkhead connector DNC-2062 is compatible with cable DNC-1106 cable .
Outline Drawing
Outline dimensions drawing of Underwater bulkhead connector M16 with Long thread for RED DSMC2 I/O, compatibility with Salty Surf housing.
